I/O DIN-rail modules
PRODUCT DETAILS
- Custom I/O modules for DIN rail with rich features
- Side-connected by RS485 bus, intended for control by PC software
- Intended for control by PC software or for stand-alone operation
- Proprietary protocol XC2, up to 1MBd speed
- Smart health self-monitoring, fuses, watchdogs etc. for safe operation
- Custom software for user application, configurable by ini files and scripts
- External control of software via TCP/IP, LabView drivers on request
- Module types:
- DIO - 24V/2-10A power outputs with current sensing and fusing, analog/digital inputs
- AIO - differential analog inputs and outputs, available ranges 0-10V, +/-10V, +/-100mV, etc.
- REL - module with classic or solid-state relays with contacs for 230V/2-5A
- XAM - universal I/O, plugin system for custom configuration. Example of plugin: galvanically isolated thermocouple-meter with cold junction compensation
- Custom modules can be developed on request
- Used e.g. in LEANCAT Hydrogen Fuel Cell Testing Stations
Most sold
| Product | Description |
| REL | 4x or 6x relays with NO contact
|
| DIO | 8x power digital output for 2-5A for inductive loads (valves) with PWM + 4x analog/digital input
|
| AIO | 4x analog input, 4x analog output
|
| AI | 4x analog input
|
| XAM 4xTC
|
8x general I/O (dig. I/O, analog I) + 4x thermocouple input
|
| XAM I2C
|
8x general I/O (dig. I/O, analog I) + 2x I2C bus for sensors (pressure, flowmeters, etc.)
|
| XAM IO
|
8x general I/O (dig. I/O, analog I)
|
| RGB | 2x RGB LED controller
|
| PWR | Power&Bus module for DIN-rail I/O modules
|
If these variants do not suit you, please contact us, we offer customized solutions!
